Double Pitch Transporteur chèn ak atachman
Anplasman: 38.1-76.2
Voye rechèch
Pwodwi Entwodiksyon
Double chèn transporteur goudwon ak atachman
| Newball Chèn No. |
Anplasman | Lajè ant enteryè plak |
Woulo dyamèt |
Pin dimansyon | Plat dimansyon | Dimansyon atachman | Ultim tansyon fòs |
Mwayèn tansyon fòs |
||||||||
| P | b1 | d1 | d2 | L | LC | h2 | t/T | G | L1 | F | W | h4 | d4 | Qmin | Qo | |
| mm | KN | |||||||||||||||
| C212AL fanatik chèn | 38.1 | 14.2 | 22.23 | 5.94 | 27.6 | 29.4 | 18.0 | 2.4 | 56.2 | 38.1 | 46.4 | 63.8 | 25 | 6.8 | 31.8 | 36.8 |
| C212AF chèn fanatik | 22.23/30 | |||||||||||||||
| C212A | 38.1 | 12.57 | 11.91 | 5.94 | 25.9 | 27.7 | 18.0 | 2.4 | 56.2 | 38.1 | 44.8 | 62 | 25 | 6.8 | 31.8 | 36.8 |
| C212AL | 22.23 | |||||||||||||||
| C212AH | 38.1 | 12.57 | 11.91 | 5.94 | 29.2 | 31.6 | 18.0 | 3.2 | 56 | 30 | 45 | 63 | 14.7 | M6 | 31.8 | 41.6 |
| C212AHL | 22.23 | |||||||||||||||
| C216AL chèn fanatik | 50.8 | 14.2 | 22.23 | 5.94 | 27.6 | 29.4 | 18.0 | 2.4 | 68.8 | 50.8 | 46.4 | 63.8 | 25 | 6.6 | 31.8 | 36.8 |
| C216AF chèn fanatik | 22.23/30-3.8 | |||||||||||||||
| C216A | 50.8 | 15.75 | 15.88 | 7.92 | 32.7 | 36.5 | 23 | 3.2 | 64 | 40 | 63 | 87 | 30 | 9 | 56.7 | 65.7 |
| C216AL | 28.58 | |||||||||||||||
| C216AF | 28.58/34.5-3 | |||||||||||||||
| C220A | 63.5 | 18.9 | 19.05 | 9.53 | 40.4 | 44.7 | 28.6 | 4.0 | 67 | 52 | 60 | 80 | 30 | 6.3 | 88.5 | 102.6 |
| C220AL | 39.68 | |||||||||||||||
| C220AF | 39.68/50-4 | |||||||||||||||
| C224A | 76.2 | 25.22 | 22.23 | 11.1 | 50.3 | 54.3 | 34 | 4.8 | 75 | 55 | 79.4 | 101.6 | 30 | 9 | 127 | 147.3 |
| C224AL | 44.45 | |||||||||||||||
| C224A | 76.2 | 25.22 | 22.23 | 11.1 | 50.3 | 54.3 | 34 | 4.8 | 60 | 38.1 | 80 | 110 | 17 | 8.1 | 127 | 147.3 |
| C224AL | 44.45 | |||||||||||||||
| Espas la ak dimansyon nan Pwodwi pou Telefòn yo ka Customized. | ||||||||||||||||
